"As the market leader in the field of acoustic solutions, we regard ourselves as a solutions provider. We do not offer a standard range but individual solutions for customer requirements which we develop together through close consultation."

Tobias S. | Sales Manager Acoustics

Leading acoustic systems

We have developed a comprehensive range of high-quality acoustic systems as well as decoupling products. These provide the perfect solution to the specific requirements of a range of floor coverings. They also meet current technical demands and have been adapted to satisfy our partners’ ambitious goals.

Only an individualised product concept can guarantee a reliable performance promise for your floor covering. Maximum product performance, sustainable product life cycles and the best possible acoustic optimisation are vital points of focus for us.

Find out more about the following product groups.

Acoustic systems

Acoustic systems for laminate and parquet

[Translate to English:] Aufgerollte Unterlagsmatte für Laminat

[Translate to English:] Grüne Unterlagsmatte für Laminat im Einsatz

[Translate to English:] Rote aufgerollte Unterlagsmatte für Laminat

[Translate to English:] Unterlagsmatte für Parkett im Einsatz

[Translate to English:] Aufgerollte Unterlagsmatte für Parkett

Acoustic systems for laminate, parquet and other hard floor coverings have special requirements. Reducing the noise from both impact and footfall are particularly important here.

These requirements vary depending on how the flooring is installed (e.g. floating or glued) and must be adapted to a sustainable product solution depending on the intended use. We have developed a product portfolio, based on polyurethane, for this area of application, which can be adapted to your requirements and needs in almost every respect.

Our products speak for themselves!

Technical Data

Densities of 500 kg/m³ to 2,000 kg/m³
Thicknesses of 1.10 mm to 3.50 mm
Permanent reduction of footfall sound levels of up to 43 %
Permanent reduction of impact sound levels of up to 26 dB
Thermal resistances from 0.01 m² K / W
Pressure stability over 450 kPa (> 45 t/m²)
Vapour barrier > 75 m
Fire classification (without top layer) up to Bfl-s1
Excellent compensation of unevenness
Gentle on the ankles and spine
Creates optimum home comfort

Customised product solution

100 % "Made in Germany"
Delivered as small or large rolls
Delivered cut to size or as pads
One-off product and colour design
Customised packaging solutions
Individual USPs

Application

Suitable for warm water underfloor heating
Can be installed floating or (full-surface) glued
Easy to work with – straightforward cutting to size with a cutter knife
No special safety at work measures necessary
Simple disposal with domestic trash

Benefits to you

Long Life Performance (LLP) = exceptionally long-lasting and resilient with no deterioration in visible and technical product features
Natural Noise Absorption (NNA) = combines very good, permanent reduction of footfall sound levels with outstanding impact noise reduction
Duroplastic resilience = duroplastic memory effect and almost 100 % recovery attributes, i.e., no reduction in thickness under static or dynamic loads.
Use of ecological, biogenic polyols = the use of special canola oil and castor oils means that up to 90 % of the product comprises naturally occurring raw materials
Extremely low emissions = free from plasticisers, asbestos, formaldehyde, halogens and heavy metals and meets the VOC Directive, afsset A+, Bl. Engel as well as the guidelines of the AGBB scheme
Poses absolutely no risk to health= contains neither solvents nor other substances that may deplete the ozone layer
Available certificates = Blauer Engel, TFI TÜV, DIBt abZ, afsset A+, Emicode EC1+, Cradle to Cradle…

Acoustic systems for design / polyurethane flooring

[Translate to English:] Aufgerollte Unterlagsmatte für Flies

[Translate to English:] Unterlagsmatte für Flies im Einsatz

[Translate to English:] Unterlagsmatte für Textilbelag im Einsatz

Acoustic systems for LVT design and polyurethane floorings (e.g. multi-layer floorings) are subject to special minimum levels of technical requirements. These differ significantly from comparable standard laminate and parquet floorings. In these product groups, the main points of emphasis should be the residual point-load behaviour, the permanent pressure stability (static and dynamic), and the impact sound reduction of the overall installation.

We have an established presence in the market and are continuously updating and developing our product range which means we are able to provide acoustic systems for a wide range of these types of flooring. This includes product solutions for classic LVT dry back and LVT click-in systems as well as loose-lay to multi-faceted, multi-layer floorings.

The following options are available.

Technical data

Densities of 1,000 kg/m³ to 3,500 kg/m³
Thicknesses of 1.10 mm to 2.00 mm
Residual point-load behaviour < 0.10 mm
Pressure stability over 1,000 kPa (> 100 t/m²)
Permanent reduction of impact sound levels of up to 19 dB
Permanent reduction of footfall sound levels of up to 22 %
Thermal resistances from 0.01 m² K / W
Optional anti-slip or self-adhesive designs
Fire classification (without top layer) up to Bfl-s1
Excellent compensation of unevenness
Creates optimum home comfort

Customised product solutions

100 % “Made in Germany”
Delivered as small or large rolls
Delivered cut to size or as pads
One-off product and colour design
Customised packaging solutions
Individual USPs

Application

Suitable for warm water underfloor heating and damp atmospheres
Can be installed floating, fixed or (full-surface) glued
Easy to work with – straightforward cutting to size with a cutter knife
No special safety at work measures necessary
Simple disposal with domestic trash

Benefits to you

Long Life Performance (LLP) = exceptionally long-lasting and resilient no deterioration in visible and technical product features
Natural Noise Absorption (NNA) = combines very good, permanent reduction of footfall sound levels with outstanding impact noise reduction
Duroplastic resilience = duroplastic memory effect and almost 100 % recovery attributes, i.e., no reduction in thickness under static or dynamic loads.
Use of ecological, biogenic polyols = the use of special canola oil and castor oils means that up to 90 % of the product comprises of naturally occurring raw materials
Extremely low emissions = free from plasticisers, asbestos, formaldehyde, halogens and heavy metals and meets the VOC Directive afsset A+, Bl. Engel as well as the guidelines of the AGBB scheme
Poses absolutely no risk to health = contains neither solvents nor other substances that may deplete the ozone layer
Available certificates = Blauer Engel, TFI TÜV, DIBt abZ, afsset A+, Emicode EC1+, Cradle to Cradle…

Acoustic systems for textile floorings

As versatile as textile floor coverings and carpet systems can be, so diverse are the possibilities for individualised acoustic systems and installation underlays. Furthermore, application areas range from ‘residential’ to ‘commercial’ and often have special requirements.

Over recent years, Windmöller GmbH has succeeded in developing solutions that can be used in a wide range of applications. The primary focus is on fixing flooring solutions to prevent slippage, and avoid accidents, enabling exceptional impact noise reduction, and optimum walking comfort. Of course, fire classifications, chair castor suitability and environmental compatibility were also carefully examined and tested.

Our unique product characteristics speak for themselves.

Technical data

Densities of 500 kg/m³ to 3,500 kg/m³
Thicknesses of 1.10 mm to 5.00 mm
Permanent reduction of impact sound levels of up to 26 dB
Fire classification (without top layer) up to Bfl-s1
Thermal resistances from 0.01 m² K / W
Pressure stability over 450 kPa (> 45 t/m²)
Vapour barrier > 75 m
Extremely low emissions and harmless to health
Excellent compensation of unevenness
Gentle on the ankles and spine
Creates optimum home comfort

Customised product solutions

100 % "Made in Germany"
Delivered as small or large rolls
Delivered cut to size or as spinal lining
One-off product and colour design
Customised packaging solutions
Individual USPs

Application

Suitable for warm water underfloor heating
Can be installed floating, fixed or (full-surface) glued
Easy to work with – straightforward cutting to size with a cutting knife
No special safety at work measures necessary
Simple disposal with domestic trash

Benefits to you

Long Life Performance (LLP) = exceptionally long-lasting and resilient no deterioration in visible and technical product features
Natural Noise Absorption (NNA) = combines very good, permanent reduction of footfall sound levels with outstanding impact noise reduction
Duroplastic resilience = duroplastic memory effect and almost 100 % recovery attributes, i.e., no reduction in thickness under static or dynamic loads.
Use of ecological, biogenic polyols = the use of special canola oil and castor oils means that up to 90 % of the product comprises of naturally occurring raw materials
Extremely low emissions = free from plasticisers, asbestos, formaldehyde, halogens and heavy metals and meets the VOC Directive afsset A+, Bl. Engel as well as the guidelines of the AGBB scheme
Poses absolutely no risk to health = contains neither solvents nor other substances that may deplete the ozone layer
Available certificates = Blauer Engel, TFI TÜV, DIBt abZ, afsset A+, Emicode EC1+, Cradle to Cradle…

Acoustic systems for ceramic floorings

Permanent noise has a direct impact on health and causes internal stress. One aspect of this is impact sound levels, particularly with ceramic flooring. Full-surface gluing of ceramic floorings to the base layer is an exceptional way of reducing noise. However,the impact is transmitted directly to the rooms below.

. In addition to the main task of improving the acoustic impact sound, a permanently intact bond must be created that can achieve sustainable pressure stability as well as a surface that remains intact without any problems. These additional, physical decoupling characteristics are achieved through the top-quality processing of carefully selected raw materials. . Only a permanently functioning system can guarantee absolute customer satisfaction.

Technical data

Densities of 1,000 kg/m³ to 3,500 kg/m³
Thicknesses of 1.50 mm to 5.00 mm
Pressure stability over 1,000 kPa (> 100 t/m²)
Permanent reduction of impact sound levels of up to 18 dB
Thermal resistances from 0.01 m² K / W
Fire classification (without top layer) up to Bfl-s1
Perfect for refurbishment projects and new builds
Very low installation heights
Extremely low emissions and poses no risk to health
Excellent compensation of unevenness
Creates optimum home comfort

Customised product solutions

100 % "Made in Germany"
Delivered as formatted or rolled goods
One-off product and colour design
Customised packaging solutions
Individual USPs

Application

Suitable for warm water underfloor heating
Can be installed fixed or (full-surface) glued
Easy to work with – straightforward cutting to size with a utility knife
No special safety at work measures necessary
Simple disposal with domestic rubbish

Benefits to you

Long Life Performance (LLP) = exceptionally long-lasting and resilient no deterioration in visible and technical product features
Natural Noise Absorption (NNA) = combines very good, permanent reduction of footfall sound levels with outstanding impact noise reduction
Duroplastic resilience = duroplastic memory effect and almost 100 % recovery attributes, i.e., no reduction in thickness under static or dynamic loads.
Use of ecological, biogenic polyols = the use of special canola oil and castor oils means that up to 90 % of the product comprises of naturally occurring raw materials
Extremely low emissions = free from plasticisers, asbestos, formaldehyde, halogens and heavy metals and meets the VOC Directive afsset A+, Bl. Engel as well as the guidelines of the AGBB scheme
Poses absolutely no risk to health = contains neither solvents nor other substances that may deplete the ozone layer
Available certificates = Blauer Engel, TFI TÜV, DIBt abZ, afsset A+, Emicode EC1+, Cradle to Cradle…

Solutions for soundproof doors

Often completely ignored, reducing the sounds in a room is actually a very important element of building acoustics. One requirement is to seal off noise as completely as possible while another is to provide absolute discretion in significant areas of a building.

For particularly efficient soundproofing, we can manufacture acoustic solutions which are perfectly matched to specific requirements and which can be fitted to suit the overall door build without any difficulty. The final product specifications will naturally vary depending on your requirements but these can be tailored and adapted to meet your specific needs.

The following options are offered for soundproof doors.

Technical data

Densities of 1,000 kg/m³ to 3,500 kg/m³
Thicknesses of 1.50 mm to 5.00 mm
Sand-free production possible
Permanent reduction of sound levels in a room of up to 40 dB
Thermal resistances from 0.01 m² K / W
Fire classification (without top layer) up to Bfl-s1
Creates optimum home comfort
Absorbs disruptive background noise
Reduces the reverberation period
Optimises the room acoustics

Customised product solutions

100 % "Made in Germany"
Delivered as large rolled goods or formatted
One-off product design
Customised packaging solutions
Individual USPs

Application

Can be installed nailed, fixed or (full-surface) glued
Easy to work with – straightforward cutting to size with a utility knife
No special safety at work measures necessary
Simple disposal with domestic rubbish

Benefits to you

Long Life Performance (LLP) = exceptionally long-lasting and resilient no deterioration in visible and technical product features
Natural Noise Absorption (NNA) = combines very good, permanent reduction of footfall sound levels with outstanding impact noise reduction
Duroplastic resilience = duroplastic memory effect and almost 100 % recovery attributes, i.e., no reduction in thickness under static or dynamic loads.
Use of ecological, biogenic polyols = the use of special canola oil and castor oils means that up to 90 % of the product comprises of naturally occurring raw materials
Extremely low emissions = free from plasticisers, asbestos, formaldehyde, halogens and heavy metals and meets the VOC Directive afsset A+, Bl. Engel as well as the guidelines of the AGBB scheme
Poses absolutely no risk to health = contains neither solvents nor other substances that may deplete the ozone layer
Available certificates = Blauer Engel, TFI TÜV, DIBt abZ, afsset A+, Emicode EC1+, Cradle to Cradle…
